Products

We can produce a very wide range of asynchronous windings thanks to dedicated but flexible equipment.

Winding range

Ø EXTERNAL	Ø INTERNAL	SLOTS	POLES
73	38	12	2
73	38	24	4
80	45	18 inclined	4
80	45	24	4
80	45	24 inclined	4
90	50	24	4
90	50	24 inclined	4
106,5	62	24	4
106,5	70	36 inclined	6
107	55	24	2
109	68	30	8
110	55	24	2
110	66	24	4
110	70	36 inclined	6
125	62	24	2
125	70	24	4
125	80	36 inclined	6
134	84	30	8
135	70	24	2 and2/4
135	80	36	4
135	90	36	6
150	90	36	4
152	80	24	2 and 2/4
152	90	36	4
152	103	36	6
160	90	27	6
173	90	36	2
173	103	36	4
173	115	36	6
173	115	36 inclined	6
197	197	36	4
200	110	36	2
200	125	36	4
200	127	36	4
200	135	36	6, 8
200	140	48	8
202	130	54	2/18, 6
210	150	36 inclined	2
220	140	36	4
230	126,4	36	8
235	150	36	4
235	150	48	4/16
240	150	36	4
240	165	54	4, 6, 8
240	135	36	2 and 2/4
243	155	36	4
250	150	54	2/18
250	150	60	2/20
250	175	54	2/4/18, 4, 6, 8
262	262	48	4
270	150	36	2
270	165	48	4
270	170	36	4
270	180	54	6
300	190	48	4
300	200	54	6, 8
300	200	54 inclined	12
300	210	60	2/20, 2/4/20, 2/24, 6, 8
300	210	72	2/24, 2/4/24, 8
340	240	54	6, 8
350	240	36 inclined	12
350	250	72	2/4/24, 8
